Mark 6

A flexible system that delivers solid results
Car-O-Liner's Mark 6 is a mobile bench system with the added convenience of drive-on mounting. It's designed around the idea that the more flexible a collision repair system is, the more productive it will be. With a series of configurations to choose from, Mark 6 means flexibility in getting the combination of equipment best suited to your business. You can even build a system of your own using a combination of benches and accessories (all accessories are interchangeable). And you can update your Mark 6 system as your needs grow.



FEATURES & BENEFITS

• Universal solution — for cars, vans, light trucks and SUVs
• Powerful — 10-ton draw aligner offers 2800 kgs of lifting capacity
• 360° multi-angle pulling
• Fast — Drive-on mounting for quick set-up, diagnosis and repair
• Compatible with EVO 1, 2 & 3 Universal Anchoring and Holding Systems
• Compatible with the Car-O-Tronic and Car-O-Mech Measuring Systems
• Strong — truck clamping accessories provide strong, no-slip, safe holding
• Versatile — interchangeable accessories allow you to build the perfect system for your shop
• Flexible — fixed, mobile or pit installations
• OEM Approved — secure, quality clamping with specific OEM options

SPECS

Length 13' (4060mm)
Length with draw aligner 17' (5180mm)
Width 900 mm  (3')
Width with draw aligner 2020 mm (6.75')
Min Height 200 mm  (7.9")
270 (10.5") mm top of cylinder
Max Height (Floor to top of platform) 1360 mm  (3.5')
Work Area Size (Draw aligner on both sides)  3140 mm² (10'sq)
Total weight, lift and work platform 680kgs (1496 lbs)
Mobile Capacity Yes (Optional)
Milled Surface for measuring Yes
Pulling Force 10 tons (per draw aligner)
Hydraulic Pressure 210 bar
Air connection Pressure Max 10 bar
Lift capacity in ground (max vehicle weight) 3000 kg
Power 3Ph, 50Hz, 200/220/400V
1Ph, 60Hz, 110/220V
